product description
|
LPV-60-12 Mean Well Power Supply 12V 60W |
|||||||
|
Model: |
LPV-60-12 |
||||||
|
DC VOLTAGE: |
12V |
||||||
|
Rated Current: |
5A |
||||||
|
Input voltage: |
90~264VAC or 127~370VAC |
||||||
|
Rated Power: |
60W |
||||||
|
Frequency Range: |
47~63Hz |
||||||
|
Leakage Current: |
0.25mA/240VAC |
||||||
|
Efficiency: |
83% |
||||||
|
Dimension: |
162.5*42.5*32mm(L*W*H) |
||||||
Detailed description of LPV-60-12 Mean Well Power Supply 12V 60W:
1) Constant voltage design
2) Universal AC input/Full range
3) Short circuit, over load, over voltage protections
4) 100% full load burn-in test
5) Fully isolated plastic case
6) Low cost, high reliability
7) Cooling by free air convection
8) class 2 power unit
9) Fully encapsulated with IP67 level
10)Withstand 300VAC surge input for 5 seconds
